4. Make sure the work area is clean, then remove the protection shield.
5. Install the bottom cover.
6. Install the top cover.
Iqon is ready for commissioning.
CAUTION: Do not switch on power to Iqon at this time. You must first register Iqon with the CMP
before power is switched on.
4.5. Commissioning
Commissioning Iqon connects it to a Charging Management Platform (CMP), ready to charge a vehicle.
In a Hub-Satellite installation, only the Hub Iqon is connected to the CMP, with the Satellites connected
through this Hub using RS485 data communication.
A Hub model can connect up to 20 connectors (1 Hub and 9 Satellites, each with two connectors) to a
CMP. The Hub uses either a pre-programmed SIM to connect to the CMP through a cellular network, or
a Wi-Fi connection to a local Wi-Fi router.
Note: It is important that Iqon is first registered with the CMP before power is supplied. This allows
Iqon to find and connect to the CMP URL automatically.
4.5.1. Con>guration details
The Iqon configuration details are on the sticker in Part B of this manual. Configuration details can also
be found on the packaging. You will need the configuration details of a Hub Iqon to commission a
standalone Hub or a Hub-Satellite installation.
4.5.2. Register EVBox Iqon with CMP
Activate the Hub Iqon with the CMP on the CMP website or using the CMP-specific app. Contact the
Charging Point Operator (CPO) for details about the charging station activation procedure.
4.5.3. Download EVBox Connect app
Use the EVBox Connect app to set up the Hub Iqon and connect it to the URL of the CMP.
Download and install the EVBox Connect app on your smartphone or tablet:
EN
