3.2. EVBox Iqon models
Iqon is either a Hub model or a Satellite model.
A Hub model can connect up to 20 connectors (1 Hub and 9 Satellites, each with two connectors) to a
Charging Management Platform (CMP). The Hub uses either a pre-programmed SIM to connect to the
CMP through a cellular network, or a Wi-Fi connection to a local Wi-Fi router.
A Satellite model does not have a SIM, a Wi-Fi connection, or Bluetooth.
3.3. Speci>cations
Feature Description
Electrical properties
Power line electrical input
2 x 3-phase 400 V AC, 32 A.
or
1 x 3-phase 400 V AC, 64 A.
Electrical output 2 x 22 kW.
Charging mode Mode 3 EVSE (IEC 61851).
Fixed charging cable 2 x Type 2 (IEC 62196-2) cables.
Charging cable length 5.5 m (18 ft).
Metering S-Bus MID certified class B.
kWh meter type 2 x ABB B23 112-100
System lighting
Day-and-night mode, automatic brightness, automatic and
touch system wake-up.
Safety and certi>cation
Safety
Safety Class I (the charging station is supplied with a
ground terminal for safety).
Overvoltage Category III.
3. Product features
EN
11
