9. Use the key to open the bottom cover of the charging station.
Put the cover front side up in a place where it cannot be damaged.
10. Use the key to open the top cover of the charging station.
Put the cover front side up in a place where it cannot be damaged.
11. Install the lifting protector.
Note: The lifting protector protects your hands from metal edges during installation.
12. With two persons, lift the charging station to the standing position.
WARNING: Do not leave the charging station standing unsecured. Secure the charging
station to a support to make sure that it cannot fall.
WARNING: Do not use the charging cables to lift or move the charging station. The cables
can become damaged which will result in the risk of electric shock and damage to Iqon, which will
cause injury and death.
13. Retract the charging cables as follows:
a. Remove the safety pin screw.
Note: Do not install the safety pin screw when the safety pin has been removed. The screw
can catch on the charging cable mechanism.
b. Remove the safety pin.
c. Place the safety pin in its holder.
d. Remove the protective caps from the charging cables, then dock the charging cables in their
holders.
e. Retract the charging cables by pushing down the levers in the cable locking mechanism.
14. Open the side covers as follows:
a. Loosen the four slide Torx screws.
b. Remove the eight thumbnuts.
c. Carefully slide open each side panel.
4. Installation instructions
