C-PRO NANO HARDWARE MANUAL
Page 19
5.2 C-PRO EXP MICRO dimensions/installation
The mechanical dimensions for the C-PRO EXP MICRO are given below; the measurements are in mm (in).
6 Accessories
6.1 User terminals (IntraBus)
User terminals allow the control units to be controlled remotely (display and commands). There are two
interface types, one panel-mounted, the other wall-mounted. The interface is connected to the special (powered)
serial connector of the C-PRO NANO controllers.
V LEDi
Panel-mounted version
V WALL
Wall-mounted version
