C-PRO NANO HARDWARE MANUAL
Page 32
EVIF21TS7I connections
Insulated interface wiring diagram
Connector
Conn. Abbrev. Description
11 + RS485+
13 - RS485-
15 shield COMMON
75 Power supply 230 V AC
77 Power supply 230 V AC
