EVCO S.p.A.
EV3 MVC & EVD MVC | Application manual ver. 2.2c | Code 1443DMVCI224
page 38 of 74
8 CONFIGURING A DEVICE
The following paragraphs list all the possible configurations of the EV3 and EVD MVC devices.
8.1 Parameters
For each parameter a visibility level is assigned that can be modified (only from serial port) with 4 possible values (the visibility value
controls the level of the password to be entered in order to access the relative parameter via the keypad):
0 = Hidden (H)
1 = User (U)
2 = Servicer (S)
3 = Manufacturer (M)
Label
Default
value
Default
visibility
Min Max um Description
TBD Time Band Parameters
t01 0 U 0 3
Time Band Mode
0: OFF
1: ON
2: Holiday ON
3: Holiday OFF
t02 26 U 0:00 23:45 15 min Start time band 1 type A
t03 2 U 0 4
Band 1 type A mode
0: Disabled
1: OFF
2: Comfort
3: Economy
4: Night
t04 32 U 0:00 23:45 15 min Start time band 2 type A
t05 3 U 0 4 Band 2 type A mode
t06 64 U 0:00 23:45 15 min Start time band 3 type A
t07 2 U 0 4 Band 3 type A mode
t08 84 U 0:00 23:45 15 min Start time band 4 type A
t09 4 U 0 4 Band 4 type A mode
t10 28 U 0:00 23:45 15 min Start time band 1 type B
t11 2 U 0 4 Band 1 type B mode
t12 40 U 0:00 23:45 15 min Start time band 2 type B
t13 3 U 0 4 Band 2 type B mode
t14 64 U 0:00 23:45 15 min Start time band 3 type B
t15 2 U 0 4 Band 3 type B mode
t16 88 U 0:00 23:45 15 min Start time band 4 type B
t17 4 U 0 4 Band 4 type B mode
t18 28 U 0:00 23:45 15 min Start time band 1 type C
t19 2 U 0 4 Band 1 type C mode
t20 40 U 0:00 23:45 15 min Start time band 2 type C
t21 3 U 0 4 Band 2 type C mode
t22 48 U 0:00 23:45 15 min Start time band 3 type C
t23 2 U 0 4 Band 3 type C mode
t24 88 U 0:00 23:45 15 min Start time band 4 type C
t25 4 U 0 4 Band 4 type C mode
t26 0 U 0 2
Band type for Monday
0: Type A
1: Type B
2: Type C
t27 0 U 0 2 Band type for Tuesday
t28 0 U 0 2 Band type for Wednesday
t29 0 U 0 2 Band type for Thursday
