14 TECHNICAL SPECIFICATIONS
Purpose of the control
device
EV3 MVC
Function controller
EVD MVC
EV3K11
EVJ LCD
Construction of the control
device
EV3 MVC
Built-in electronic device
EVD MVC
EV3K11
EVJ LCD
Housing
EV3 MVC Black, self-extinguishing
EVD MVC Grey, self-extinguishing
EV3K11 Black, self-extinguishing
EVJ LCD White, self-extinguishing
Category of heat and fire
resistance
EV3 MVC
D
EVD MVC
EV3K11
EVJ LCD
Measurements
EV3 MVC 75.0 x 33.0 x 59.0 mm (2.952 x 1.299 x 2.322 in)
EVD MVC 71.0 x 110.0 x 60.0mm (2.795 x 4.330 x 2.362 in); 4 DIN modules
EV3K11 75.0 x 33.0 x 39.5 mm (2.952 x 1.299 x 1.555 in)
EVJ LCD 111.4 x 76.4 x 18.5 mm (4.384 x 3.007 x 0.727 in)
Mounting methods for the
control device
EV3 MVC To be fitted to a panel, snap-in brackets provided
EVD MVC
On a DIN rail 35.0 x 7.5 mm (1.377 x 0.295 in) or 35.0 x 15.0 mm (1.377 x 0.590 in), in
a control panel
EV3K11 To be fitted to a panel, snap-in brackets provided
EVJ LCD
Wall-mounted (with fixing screws and plugs) or in a built-in 502E or 503E box (with fixing
screws)
Degree of front protection
EV3 MVC IP65
EVD MVC IP40
EV3K11 IP65
EVJ LCD IP30
Connections
EV3 MVC
- Micro-Fit connector (power supply, analogue inputs, digital inputs, analogue outputs
and INTRABUS port)
- Edge connectors (digital outputs)
- Plug-in screw terminal block (RS-485 MODBUS port).
EVD MVC
- Micro-Fit connector (analogue inputs, digital inputs, open collector output)
- Plug-in screw terminal blocks (power supply, electro-mechanical relays, INTRABUS port
and RS-485 MODBUS port).
EV3K11 Plug-in screw terminal block (power supply and INTRABUS port).
EVJ LCD Fixed screw terminal block (power supply and INTRABUS port).
