Evco EV3 MVC Applications Manual

EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 2.2c | Code 1443DMVCI224
page 44 of 74
8.2.1 Configuring input functions
Parameter value
I01 - I10
Description
0 Disabled
1 Supply fan thermal switch
2 Return fan thermal switch
3 Supply flow switch
4 Return flow switch
5 High pressure
6 Low pressure
7 Compressor thermal switch
8 Remote ON-OFF
9 Operating mode changeover
10 Coil water antifreeze
11 Heater thermal switch
12 Thermostat request
13 Dehumidifier request
14 External air damper open limit switch
15 External air damper closed limit switch
16 Forced ventilation
17 Dirt filters
18 Heat pump status
19 Fire alarm
20 unused
21 unused
22 Supply fan tachometer
23 Return fan tachometer
100 Room probe
101 Supply probe
102 External probe
103 Discharge probe
104 Water probe 1
106 Compressor defrost probe
107 Compressor discharge temperature probe
108 unused
109 unused
