1.4. EPTZ3600/EPTZ3600I Quick Operation Guide (Work with EKB500)
EPTZ3600/EPTZ3600I and EKB500 (Keyboard) can work together by using factory
default setting. You just need to connect cables by the following steps:
Pin #
Function
1
ALM_NO_B (Alarm Output Normal Open B)
2
ALM_COM_B (Alarm Output Common B)
3
ALM_NC_B (Alarm Output Normal Close B)
4
ALM_NO_A (Alarm Output Normal Open A)
5
ALM_COM_A (Alarm Output Common A)
6
ALM_NC_A (Alarm Output Normal Close A)
7
ALMIN1 (Alarm Input 1)
8
GND (Ground)
9
ALMIN2 (Alarm Input 2)
10
ALMIN3 (Alarm Input 3)
11
GND (Ground)
12
ALMIN4 (Alarm Input 4)
13
VIDEO+
14
VIDEO-
15
RS485-
16
RS485+
17
AC24A+
18
AC24B-
