65
confirm selection.
d. DURATION: Duration of alarm input.
TIMEOUT: Turn the joystick Left or Right to select on TIMEOUT and press Enter key
to select time-out. Time-out is selectable from 1~99. Press Enter key again to confirm
selection.
LATCHED: Turn the joystick Left or Right to select on LATCHED. The alarm output
will not stop until there is any operation on keyboard.
TRANSPARENT: Turn the joystick Left or Right to select on TRANSPARENT. The
alarm output will not stop until the alarm is stopped.
e. PRIORITY: Turn the joystick Left or Right to select alarm input priority, it is selectable
from 1234/2341/3412/4123.
f. RETURN: Turn joystick Left/Right to return to previous menu.
3.6.2. ALARM OUTPUTS
Press Enter key of keyboard to enter ALARM OUTPUTS sub-menu. (see diagram 3.36)
(diagram 3.36)
ALARM OUTPUT TRIGGER
OUTPUT NO 1
INPUT1 YES
INPUT2 YES
INPUT3 YES
INPUT4 YES
MOTION NO
SYSTEM ERROR NO
REMOTE NO
RETURN
ALARM INPUTS<┘
ALARM OUTPUTS <┘
MOTION DETECT <┘
EXIT
