Pull open this switch
pasted and the alarm and video cables are reconnected, return the base board to its
original position. You will need to pull open the switch again in order for it to fit properly.
Note:
To close the base board, please push the base board twice consequently to lock it up.
4. Put the waterproof silicon pad on top of the base board for waterproof purpose.
5. Connect the RS485, video, and power cables through the top hole of the base board. If
necessary, connect the alarm cable as well using the bottom hole.
