Onboard Device
Press Enter to display the Onboard Device menu.
 Realtek GigaLan
Use this function to set the onboard Realtek GigaLan function for LAN1.
The options are Auto, Enabled and Disabled.
 PE4 Slot (PCIE x1)
Use this function to set the PCI-e x1 Slot function. The options are Auto,
Enabled and Disabled.
 Realtek Lan PXE Boot ROM
This function allows you to enable or disable the onboard Realtek Lan PXE
Boot ROM for booting from LAN.
 High Definition Audio
This function allows you to enable or disable the onboard Realtek High
Definition Audio.
 TI 1394 Setting
This function allows you to enable or disable the IEEE1394 (Firewire)
interface.
 P80 Show CPU Temp.
When this function is enabled the onboard Post Port LED will display the
CPU temperature.
Realtek GigaLan [Auto]
PE4 Slot (PCIE x1) [Auto]
Realtek Lan PXE Boot ROM [Disabled]
TI 1394 Setting [Enabled]
High Definition Audio [Enabled]
P80 Show CPU Temp. [Enabled]
