Configuring the BIOS
61
Voltage Control
Select Voltage Control from the Frequency/Voltage Control menu and press
Enter to display the Voltage Control menu.
Figure 13. Voltage Control
EVGA VDroop Control
EVGA VDroop control is a safety measure by motherboards to protect the
CPU. Select [With VDroop] to calibrate CPU VDroop or select [Without
VDroop] to disable this function
CPU VCore
Use the Page Up and Page Down keys to scroll through the voltages or
select [Auto] to automatically set the voltage level for the CPU Core.
CPU VTT Voltage
Use the Page Up and Page Down keys to scroll through the voltages or
select [Auto] to automatically set the voltage level for the CPU VTT Voltage.
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F7: Defaults
EVGA VDroop control [With VDroop]
CPU VCore [Auto] 1.2750V
CPU VTT Voltage [Auto] +0mv
CPU PLL Vcore [Auto] 1.800V
QPI PLL Vcore [Auto] 1.100V
DIMM Voltage [Auto] 1.500V
DIMM DQ Vref [+0mv] +0mv
IOH Vcore [Auto] 1.100V
IOH/ICH I/O Voltage [Auto] 1.500V
ICH Vcore [Auto] 1.050V
Users should exercise caution when over-
voltaging, as it can cause system instability
or even void warranties and damage components.
Phoenix – AwardBIOS CMOS Setup Utility
Voltage Control
To Next Page
