 CPU PLL VCore
Use the Page Up and Page Down to scroll through the voltages or select
[Auto] to automatically set the voltage level for the CPU PLL Voltage.
 QPI PLL VCore
Use the Page Up and Page Down to scroll through the voltages or select
[Auto] to automatically set the voltage level for the QPI PLL Voltage.
 DIMM Voltage
This function defines the voltage level for the DRAM. Use the Page Up and
Page Down keys to select a voltage or select [Auto] to automatically set the
voltage.
 DIMM DQ Vref
This function defines the voltage level for the DRAM DQ Vref. Use the
Page Up and Page Down keys to select and set the voltage.
 IOH VCore
This function defines the core voltage level for the Intel IOH chip. Use the
Page Up and Page Down keys to select a voltage or select [Auto] to
automatically set the voltage.
 IOH/ICH I/O Voltage
This function defines the core voltage level for the Intel IOH/ICH I/O
voltage. Use the Page Up and Page Down keys to select a voltage or select
[Auto] to automatically set the voltage.
 ICH VCore
This function defines the core voltage level for the Intel ICH chip. Use the
Page Up and Page Down keys to select a voltage or select [Auto] to
automatically set the voltage.
CPU Feature
Select CPU Feature from the Frequency/Voltage Control menu and press
Enter to display the CPU Feature menu.
