Evolis Primacy - Page 43

43
To e xc ha ng e the print he a d, ple a se pro c e e d a s follows:
Be fo re c ha ng ing the print he a d, ple a se unplug the po we r c a b le .
ä
Ste p 1 - Re m o ving the de fe c tive print he a d
Ê
O p e n the p rinte r c o ve r.
Ë
Lo c a te the p rint he a d .
Ì
Pre ss o n the p la stic p a rt b e hind the he a d (p re ssure p la te ) a nd p ull o n the he a d with the o the r ha nd a s sho wn in the
d ia g ra m in o rd e r to fre e the lug s fro m the ho ld ing fo rk, the n re mo ve the lug s fro m the ir slo ts.
Í
Tilt the he a d c a re fully d o wnwa rd s a nd d isc o nne c t the c o nne c to r linke d to the c a b le witho ut using fo rc e o n the
me c ha nism .
4
Ê
Ì
Í
Ë
