Command sequence for positioning the contactless smartcard
A sequence of commands must be sent via the printer’s interface to insert a card in the printer then position it close to the antenna to
establish radio communication between the card and the encoder.
The command sequence is as follows:
Sending the SIC sequence:
O A card is moved from the feeder towards the antenna and is positioned nearby.
O The chip is programmed via the computer’s serial (or USB) interface connecting the built-in encoder and the computer.
Refer to the Evolis printer Programming Guide for further details on programming contactless smartcards.
Refer to the KU15 ‘Quantum Encoding Module’ manual for further details on connecting the smartcard encoder.
