1-4 Encoding module
1-4a GENERAL REMARKS
The printer is equipped with a multi-function, detachable and reversible
encoding module.
contact and contactless smartcards.
Completely independent, it handles all the stages in an encoding run, at the same time as the
printing jobs handled by the other module.
This encoding module is reversible, which means the user can turn the whole module round
at once.
This unique feature means that cards can be encoded and printed in a single pass, without
turning them over. The total card customisation time is therefore considerably reduced.
The location of the encoding module is shown by the label stuck on it.
Position A = magnetic strip encoder in upper position and smartcard contact station in lower position.
smartcard encoders to be mounted.
An attachment support found on the back of the
Before attempting any work on the encoding module, it is essential to turn the machine off and unplug the
power cable.
For further details about the encoding module and its features, please refer to the KU15 manual available from
your Evolis dealer.
