PLEASE NOTE: EazyPod Automatic is designed to be used on a PUMP FED SET-UP ONLY.
The EazyPod Automatic MUST NOT be installed as a Gravity Fed set-up.
The diagram below shows the EazyPod Automatic on a typical Pump Fed set-up.
A Pump Fed set-up is when water is pumped from the pond to the filter.
INSTALLATION
3” (90mm) or 4” (110mm) pipe
POND
Return to pond
Pump
Raised 12”
off ground
1½” pipe
Non-return
hosetail
PLEASE NOTE: The pump must not be placed on the base of the pond, as failure in the pipe
work or connectors could lead to complete drainage of the pond. The pump should be raised at
least 12” off the ground or high enough to leave sufficient water for the fish to survive, in the
unlikely event that this occurs.
IMPORTANT: A solid, level base is required for the EazyPod Automatic. It should be a minimum of
600mm x 600mm, to allow easy access to your valves and for maintenance purposes.
The EazyPod Automatic filter needs to be supported evenly on a level base (a paving flag is ideal).
Failure to do so could cause damage when it is full of water.
11
