MACHINE OVERVIEW
1. FIXINGS GROUPED IN SETS
3. TABLE EXTENSIONS AND STRUTS ETC
A: 2 X SIDE TABLE EXTENSIONS
B: 4 X SIDE TABLE SUPPORT STRUTS
2.THE STAND COMPONENTS
A: 4 X BLACK CORNER LEGS
B: 4 X RUBBER FEET
C: 2 X BLACK TOP CROSSPIECES LONG
D: 2 X BLACK TOP CROSSPIECES SHORT
E: 2 X GREEN CROSSPIECES LONG
F: 2 X GREEN CROSSPIECES SHORT
G: 2 X REAR CANTILEVER BRACES
4. OTHER PARTS
A: BLADE GUARD
B: ANTIBOUNCE DEVICE
C: RIP FENCE
D: MITRE GAUGE
E: FENCE RAIL 2 PIECE
A
A
B
C
A
B
C D E F
G
DE
B

Evolution FURY5 Specifications

General

Blade Diameter	255 mm
Motor Power	1500 W
Bevel Capacity	45°
Bore	25.4 mm
Mild Steel Plate Thickness (Max.)	6 mm
Motor (230V~50 Hz)	1500 W
Voltage	230 V
Frequency	50 Hz
