Evolution FURY5 User Manual

6
www.evolutionpowertools.com
SPECIFICATIONS
CUTTING CAPACITY METRIC IMPERIAL
Maximum depth of cut at 90
0
73mm 2-7/8”
Maximum depth of cut at 45
0
54mm 2-1/8”
Mild Steel Plate – Optimal Cutting Thickness 3mm 1/8”
Mild Steel Box Section – Opt. Wall Thickness 3mm 1/8”
MACHINE METRIC IMPERIAL
Motor (UK) 230v ~ 50/60Hz 1500W (S6 40%) 7A
Table Dimensions 625 x 812mm 24-5/8 x 32”
Riving Knife Thickness 1.8mm 1/8”
Speed No Load 2500min
-1
2500rpm
Weight 28kg 62lbs
BLADE METRIC IMPERIAL
Diameter 255mm 10”
Bore 25.4mm 1”
Number of Teeth 24 24
Kerf 2mm 1/8”
Max Speed 2750min
-1
2750rpm
NOISE & VIBRATION DATA
Sound Pressure L
P
A (Under Load) 93dB(A) K=3dB(A)
Sound Power Level L
W
A 104.3dB(A) K=3dB(A)
Vibration Level (Under Load) 1.39 m/s
2
K = 1.5 m/s
2

Evolution FURY5 Specifications

General

Brand	Evolution
Model	FURY5
Category	Saw
Language	English
