1. Battery 2. Motor
Controller
3. Charger port 4. ON/OFF
switch
5. USB ports 6. Front truck 7. Rear truck
8. Motors 9. Belt 10. Deck 11. Motor Plate 12. Drive Gear 13. All Terrain
Wheels
14. Street
Wheels
BAMBOO GTR
10
6
4 13
8 255
9
11
12
7
14
13
