Evolve BAMBOO GTR - Page 9

/9
CARBON GTR
1. Battery 2. Motor
Controller
3. ON/OFF
switch
4. Charger port 5. Front truck 6. Rear truck 7. Motors
8. Deck 9. Motor Plate 10. Belt 11. Drive Gear 12. All Terrain
Wheels
13. Street
Wheels
5
34 12
7 8
96
121110
13
