3 Cabling
3.1 XT 6U Back Plane, Muticam mode
PN:
SN:
MADE IN E.U.
LTC
Timecode
reference
EVS Remote #1
RS 422
RS 232
RS 422 RS 422
1 2 3
Tab let
Data Screen
(VGA or B&W video
using adapter)
Default RS422 Config :
#1 : EVS remote #1
#2 : EVS remote #2
#3 : EVS remote #3
#4 : Sony BVW75 Protocol
#5 : Sony BVW75 Protocol
#6 : Touch Screen
Any of the following
RS422 protocols :
- Sony BVW75
- XtenDD35
- Louth VDCP
- EVS AVSP
Analog
Genlock
Reference
RS 422
4
OR
RS 422
5
RS 422
6
LTC OUT
PGM 1
OR
=
OROR
Keyboard
Touch
Screen
EVS Rem. #2 EVS Rem. #3 RS422 Protocol RS422 Protocol
RS422 Protocols EVS Rem. #4 RS422 Protocol
Important : Genlock loop must be terminated if not used.
