EVS XT Series Technical Reference

XT Series DISK RECORDER - Technical Reference
EVS Broadcast Equipment SA - Nov 2005
Issue 3.0
32
CODEC6 board.
A
COD0
C
COD4
B
COD2
E
COD3
F
COD5
D
COD1
2 Play + 0 Rec
Play 1 Play 2
1 Play + 1 Rec
Play 1 Rec 1
0 Play + 2 Rec
Rec 2 Rec 1
3 Play + 0 Rec
Play 1 Play 3 Play 2
2 Play + 1 Rec
Play 1 Play 2 Rec 1
1 Play + 2 Rec
Rec 2 Play 1 Rec 1
0 Play + 3 Rec
Rec 2 Rec 3 Rec 1
4 Play + 0 Rec
Play 1 Play 3 Play 2 Play 4
3 Play + 1 Rec
Play 1 Play 3 Play 2 Rec 1
2 Play + 2 Rec
Play 1 Rec 2 Play 2 Rec 1
1 Play + 3 Rec
Play 1 Rec 2 Rec 3 Rec 1
0 Play + 4 Rec
Rec 4 Rec 2 Rec 3 Rec 1
5 Play + 0 Rec
Play 1 Play 3 Play 4 Play 5 Play 2
4 Play + 1 Rec
Play 1 Play 2 Play 3 Play 4 Rec 1
3 Play + 2 Rec
Play 1 Rec 2 Play 2 Play 3 Rec 1
2 Play + 3 Rec
Play 1 Rec 2 Rec 3 Play 2 Rec 1
1 Play + 4 Rec
Rec 4 Rec 2 Rec 3 Play 1 Rec 1
0 Play + 5 Rec
Rec 4 Rec 2 Rec 3 Rec 5 Rec 1
6 Play + 0 Rec
Play 1 Play 5 Play 3 Play 4 Play 6 Play 2
5 Play + 1 Rec
Play 1 Play 4 Play 2 Play 3 Play 5 Rec 1
4 Play + 2 Rec
Play 1 Play 3 Rec 2 Play 2 Play 4 Rec 1
3 Play + 3 Rec
Play 1 Play 3 Rec 2 Rec 3 Play 2 Rec 1
2 Play + 4 Rec
Play 1 Rec 4 Rec 2 Rec 3 Play 2 Rec 1
1 Play + 5 Rec
Play 1 Rec 4 Rec 2 Rec 3 Rec 5 Rec 1
0 Play + 6 Rec
Rec 6 Rec 4 Rec 2 Rec 3 Rec 5 Rec 1
-
4.2.2.1 LED’S INFORMATION:
LA: flashes when the DSP program is running.
LB: lights when the channel is in use, either in record or in playback
mode.
TF: flashes while data transfer is in process between the CODECs and
the HCTS boards
One TF LED is also available from the front of the CODEC board. This LED
summarizes the activity of all TF LED’s present on each CODEC module.
4.2.2.2 BOARD CONFIGURATION:
No modifications are required for this specific board.
Do not modify the jumpers positions.
