CAHB-20 series

4.1 Overview

CAHB- 20 E

Include 3 types outline.

4.0 Structure and function

Fig. 3

CAHB-20 E without position feedback

1. Front hinge head

2. Push tube

3. Guiding tube (Steel tube)

4. Motor

5. Cable

6. Rear hinge head

7. Gearbox

Fig. 4

CAHB-20 E with position feedback

8. Middle housing

Fig. 5

CAHB-20 E with manual override (Manual

override option can be congured on all series)

9. Manual override part

2 3
