Machine description – quick overview
Front view
16
099-005320-EW501
22.05.2014
4 Machine description – quick overview
NOTE
The maximum possible machine configuration is given in the text description.
If necessary, the optional connection may need to be retrofitted (see "Accessories"
chapter).
4.1 Front view
Figure 4-1
