EWM Phoenix 405 Progress puls TDM - Venting the Coolant Circuit

Rectifying faults
Vent coolant circuit
46
099-005320-EW501
22.05.2014
7.5 Vent coolant circuit
NOTE
Coolant tank and quick connect coupling of coolant supply and return are only fitted in
machines with water cooling.
To vent the cooling system always use the blue coolant connection, which is located as
deep as possible inside the system (close to the coolant tank)!
Figure 7-3
