Technical data
Phoenix 505
099-005320-EW501
22.05.2014
49
8.3 Phoenix 505
TIG
MIG/MAG
MMA
Setting range for welding current
5 A–500 A
Setting range for welding voltage
10.2 V–30.0 V
14.3 V–39.0 V
20.2 V–40.0 V
Duty cycle
40 °C
25 °C
40 °C
25 °C
40 °C
25 °C
60 %
500 A
-
500 A
-
500 A
-
65 %
-
500 A
-
500 A
-
500 A
100 %
430 A
460 A
430 A
460 A
430 A
460 A
Load alternation
10 min. (60% DC

6 min. welding, 4 min. pause)
Open circuit voltage
79 V
Mains voltage (tolerances)
3 x 400 V (-25% to +20%)
Frequency
50/60 Hz
Mains fuse
(safety fuse, slow-blow)
3 x 32 A
Mains connection lead
H07RN-F4G6
Max. connected load
18.9 kVA
24.6 kVA
25.2 kVA
Recommended generator rating
34.0 kVA
cos
0.99
Insulation class/protection
classification
H/IP 23
Ambient temperature
-25 C to +40 C
Machine/torch cooling
Fan/gas
Workpiece lead
95 mm
2
Dimensions (L x W x H)
625 mm x 300 mm x 535 mm
Weight
45 kg
EMC class
A
Constructed to standards
IEC 60974 -1, -10 / /
