Design and function
Notes on the installation of welding current leads
26
099-005221-EW501
16.04.2014
NOTE
Use an individual welding lead to the workpiece for each welding machine!
Figure 5-3
NOTE
Fully unroll welding current leads, torch hose packages and intermediate hose
packages. Avoid loops!
Always keep leads as short as possible!
Lay any excess cable lengths in meanders.
Figure 5-4
