5.15 Machine configuration menu
5.15.1 Selecting, changing and saving parameters
NOTE
ENTER (Enter the menu)
• Switch off the machine at the main switch.
• Press and hold the "welding procedure" push-button and switch the machine on again at
the same time.
NAVIGATION (Navigate the menu)
• Select parameters by turning the "welding parameter setting" rotary knob.
• Set or change the parameters by turning the "welding voltage" rotary knob.
EXIT (Exit the menu)
• Press the "gas test" push-button (switch machine off and on again).
ENTER
EXIT
+
NAVIGATION
l
0
l
0
Figure 5-24
Display
Setting/selection
Lead resistance 1
Lead resistance for the first welding circuit 0 mΩ–60 mΩ (8 mΩ ex works).
Only qualified service personnel may change the parameters!
Time-based power-saving mode
• 5 min.–60 min. = Time to activation of power-saving mode in case of inactivity.
• off = inactivated
5.15.2 Power-saving mode
The power-saving function can be activated either by pressing the button for a longer time (see chapter
"Machine description – Short overview") or by setting a parameter in the configuration menu (time-based
power-saving mode).
When power-saving mode is activated, both machine displays show the horizontal digit in the
centre of the display only.
Pressing any operating element (e.g. tapping the torch trigger) deactivates power-saving mode and the
machine is ready for welding again.
