eWON 4005CD - 5.8. Embedded HSUPA [Penta-Band]Modem EW4620 B (optional)

Chapter 5
Specifications of communication & I/Os Interfaces
5.8. Embedded HSUPA [Penta-Band]Modem EW4620B [Since S/N 1537-0108-xx included](optional)
Specification HSUPA
Bands
Quad band EGSM (850/900/1800/1900 MHz)
Penta band HSUPA (850/900/1700/1900/2100 MHz)
Class
GPRS Multi-slot Class 33
EDGE Multi-slot class 33
Max baud rate
921 kbps (theoretical)
Compliant to standards
R&TTE, CE, FCC
Certificate number
- - -
Antenna connector (*)
Type SMA-F
(*) Tightening torque for SMA antenna connector: MAX 0.5N.m (manual tightening should be used as
a reference) See Antenna.
5.9. SIM-Card installation
Sim card installation is common to:
• GPRS-EDGE Modem
• GPRS quad band Modem
• UMTS Modem
• UMTS/HSUPA Modem with part number EW4620B
For HSUPA modem with part number EW26206B only,
the SIM-card drawer is located on the top of the eWON.
