Chapter 5
Specifications of communication & I/Os Interfaces
5.10. Configurable serial port
Specification Value
Physical modes (configurable)
RS232/RS485/RS422
Isolation
1 kV by optocoupler
Pin-out connector
See Serial Port
The configuration of the physical serial mode is done by a set of 4 dip switches
located on left side of the unit.
The settings of the switches
are shown in the table below
(note: switch 1 is the right one)
Page 22 / 39 eWON 4005CD | IG 002
