Excell 320S - Appendix 2: Function Table (Continued); F and F1 Function Settings; Front Panel Indication and Zero Band Settings

04012XXX
EXCELL PRECISION CO., LTD
ZSME400000011
67
FNC-04
“F” function setting
Parameter  Description
0  Display Net / Gross weight
1  Setpoint parameter setting
2  Tare reset
3  Manual serial, parallel print output
4  Start load
5  Stop load
6  Start comparison
7  Unload command
8  Totalise weight and counts
command
9  Clear totalised weight and counts
10  Hold mode
11  Escape Hold mode(I / O DSP)
12  Convert to Gross / Net / totalised
weight / totalised Count
1
FNC-05
“F1” function setting
0
Item
Function
Setting value
Default
Parameter
Description
FNC-06
Front panel indication “◄”
setting (top)
Parameter  Description
0  Zero
1  Stable
2  Gross
3  Net
4  Totalised weight (Accu. V)
5  Totalised transactions (Accu. C)
6  SP1
7  SP2
8  SP3
9  Hi
10  OK
11  Lo
12  Under
13  Over
14  Discharge
15  Running
16  Hold
17  MD
0
FNC-07
Front panel indication “◄”
setting (next to top)
1
FNC-08
Front panel indication “◄”
setting (next to bottom)
2
FNC-09
Front panel indication “◄”
setting (bottom)
3
FNC-10
Return to zero band
(d: refer to CSP-03)
0
5 d
0
1
10 d
2
20 d
3
40 d
4
60 d
5
80 d
6
100 d
