RS-232 Interface Format
I . Mode: UART Signal of EIA-RS0232 C
II . Format :
1. Baud rate : 1 200, 2 400, 4 800, 9 600 bits/second
2. Data bits : 8 bits
3. Parity bit : None
4. Stop bits : 1 bit
5. Code : ASCII (Exchange code of American standard)
Start bit Data bits Stop bit
RS-232 Data Format
Stable transmission (r n P 1), Continuous (r n P 2), Press key to transmit (r n P
8)
1. gram as weight unit
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
g
HEAD , HEAD , ± DATA UNIT CR LF
2. kg or lb as weight unit
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
kg/lb
HEAD , HEAD , ± DATA UNIT CR LF
HEAD1 ( 2 BYTES )
HEAD2 ( 2 BYTES )
OL - Overload , Under load
TR - TARE Mode
ST - Display is Stable
NT - NET Mode
US - Display is Unstable
GS - GROSS Mode
DATA ( 7 or 8 BYTE )
2B ( HEX ) = “ + ” ( PLUS)
r n P 0

No transmission.
r n P 1

Stable transmission.
r n P 2

Continuous transmission.
r n P 3

Press key to transmit totalized simple format.
r n P 4

Press key to transmit totalized complete format.
r n P 5

Stable transmission in totalizing mode. Same format as (r n P 3).
r n P 6

Press key to transmit simple free format. Please refer to F14.
r n P 7

Press key to transmit complete Free format. Please refer to F14.
r n P 8

While use Hold, press key to transmit same format as (r n P 1) and (r n P 2).
r n P 11

Print after removing goods (5% mode).
r n P 12

Print after removing goods (OK mode).
When FB530 has mini printer, it only works in r n p 3~ r n p 7, and r n p 1, 2, 8, 11, 12 are
disabled.
