Excell FB530 User Manual

EXCELL PRECISION CO., LTD.
0201810X ZSME300000292
5
:
“Low battery
power” indication
▼6 is Range 1 ▼5 is Range 2
1-3 Keypad Functions Description
1-4 Power Description
Power
Battery
6V 4Ah Rechargeable battery
Plugged in
110V / 220V AC
Power
consumption
with 1X350Ω
load cell
without printer
No backlight
26 mA
Single display with
backlight
32 mA
Dual display with
backlight
40 mA
with printer
When not in printing
20mA
While in printing
40mA
Low Power Alarm
Please note when the ( ) symbol keeps flashing on the left down corner of the
display, the batteries should be recharged.
 When the low battery warning symbol shows up, scale is turned off automatically after
5~10 hours if it is used without backlight (1~2 hours if it is used with backlight). Then scale
must be fully recharged, before operating again.
 Please recharge at once when the symbol shows in order to keep the weight
accuracy.
Memory power supply for FB530
 When AC battery is cut off and Lead acid battery voltage is lower than 3V, the data in
RTC IC can maintain for 24 hours.
1-5 Error Messages
oL  Weight exceeds 9d of maximum capacity. (d=division)
E1  Zero value after power on is over +10% FS.
Loop select from the preset units
Go into counting mode
Preset weight and quantity for
weight check or quantity check
Press this key to sample
Accumulate weight or quantity
Press this key to confirm
Tare to deduct the container weight
Press this key to enable/disable
backlight
Set preset tare
Press this key to print
Recall the totalization value, preset
value and pre-tare value
Press this key to input number
0~9
Clear the totalization value, preset
value and pre-tare value.
Press this key to feed the paper
Zero the scale.
