EXCELL PRECISION CO., LTD.
0201810X ZSME300000292
21
RS232 DATA FORMAT
Stable transmission (r n P 1), Continuous (r n P 2), Press key to transmit (r n
P 8)
1. e.g. Machine ID code is 10.
The gross weight (+0.876 kg) shows as below, after stable: (no tare or pre-tare mode)
1
0
S
T
,
G
S
,
+
0
0
0
.
8
7
6
k
g
<CR>
<LF>
ID HEAD1 , HEAD2 , DATA UNIT
2. e.g. Machine ID code is 00. (Not using Machine ID function.)
The net weight (-1.568 lb) shows as below without weight stability: (under tare or pre-tare mode)
U
S
,
N
T
,
-
0
0
1
.
5
6
8
l
b
<CR>
<LF>
HEAD1 , HEAD2, DATA UNIT
3-7 F12 Print Key ( ) Function Setting
Press key or key to select F12
Press key
Press key
Print key setting:
Use and to set 0~2. Default setting: 0
P r F 0 If weight variation is beyond ±1d ~ ±10d,
key print totalized weight. Otherwise print current
weight. (d=division)
P r F 1 key print current weight. No totalization.
P r F 2 key print current weight if it is within the
lower and upper limits (ok range). No totalization.
