Excell FB530 User Manual

EXCELL PRECISION CO., LTD.
0201810X ZSME300000292
13
3-2 F5 RS232 and Mini Printer Output Setting (option)
 The mini printer interface default setting is 9600, N, 8, 1, and it also contains the RTC
setting.
 Our company provides the printing title editing software. If you would like this service,
please contact your local dealer.
Use or key to select F5
Transmission mode：use key to select r n P 0 ~ r n
P 14 and press to save
RS-232 baud rate：use key to select 1200~9600 and
press to save
Press key
Press key
Press key
Below need to connect to Mini Printer before continue (only available in FB530)
Press key
Press key
Press key
Press key
Press key
Press key
Mini Printer Printing Languages:
Use key to select
0~3, and press key to save.
Default is 0
⇒
Iran font (date output is based on the solar calendar)
1
⇒
English font; 2
⇒
Traditional Chinese font;
3
⇒
Simplified Chinese font
Date Printing Order Setting:
u
se key to select
F0~F2, and press key to save. Default is F0
⇒
YY MM DD
F1 ⇒ MM DD YY; F2 ⇒ DD MM YY
Input Year, Month, Day:
u
se key and key to
enter
.
F0
⇒
YY MM DD; F1
⇒
MM DD YY; F2
⇒
DD MM YY
Input Hour, Minute, Second:
u
se key and
key to enter
HH MM SS
