Excell FDH3-W User Manual

EXCELL PRECISION CO., LTD.
0201813X ZSME300000366
16
Stable Transmission in totalizing mode (r n P 5)
S/N WT/UNIT ( kg / lb )
- - - - - - - - - - - - - -
0001 1.0000  The scale is stable
0002 1.0000  The scale is stable
0003 1.0000  The scale is stable
0004 1.0000  The scale is stable
0005 1.0000  The scale is stable
- - - - - - - - - - - - - -
0005 5.0000  Press twice to print TOTAL
Press key to transmit simple free format (r n P 6)
Same format as (r n P 3). Print the complete format for the first time. Then only print NET weight.
Please refer to F14 for details.
Press key to transmit complete free format (r n P 7)
Same format as (r n P 4). Print the complete format all the time. Please refer to F14 for details.
While use Hold, press key to transmit (
r n P 8
)
If there is only RS-232, press to print out the HOLD value on the display in HOLD
MODE.
Print after Removing Goods (5% mode) (r n P 11)
Stage
Condition(s)
Action(s)
1: Goods placed
and weighed on
platter
Weight has become stable.
Weight > zero point
Weight ≥ 20 weighing units
(i.e. 5% x Weight ≥ 1 weighing unit)
Beeper beeps twice, and
printing data (stable weight
compliant with conditions on
the left) is ready to be sent.
2: Just removed
goods from platter
Instantaneous weight reading drops
below 95% of last stable weight (stable
weight of Stage 1)
Printing data of Stage 1 is
sent to the printer (same
printing formats as those of
(r n P 1).
Print after Removing Goods (OK mode) (r n P 12)
Stage
Condition(s)
Action(s)
1: Goods placed
and weighed on
platter
Weight has become stable.
Weight > zero point
Check weighing OK status (within a
predetermined weight range)
Beeper beeps twice, and
printing data (stable weight
compliant with conditions on
the left) is ready to be sent.
2: Just removed
goods from platter
Instantaneous weight reading drops
below 95% of last stable weight (stable
weight of Stage 1).
Printing data of Stage 1 is
sent to the printer (same
printing formats as those of
(r n P 1).
r n P 13  MODBUS Function, Use with F11 ID Code Setting
Formats as in r n P 1 (stable), r n P 2 (continuous), r n P 8 (key), please refer to F11 for details.
