Excell FDH3-W User Manual

EXCELL PRECISION CO., LTD.
0201813X ZSME300000366
17
Stable Transmission Only Weight Value Is Transmitted (r n P 14)
No +/-. If display is 1.000kg , transmit
r n P 15  Enter Serial number, Reply Serial Number and Weight
Enter the serial number (up to 64 characters), if you enter the SN number: SN0001<CR><LF>, if
it displays 1.000kg, etc. After stable, RS232 output format: SN0001,001.000kg<CR><LF>
r n P 16  Continuous Output Contains High, Low, Ok Status
The continuous output format is similar to r n p 2, the first code of HEAD2 is gross/net weight,
and the second code output includes High(H), Low(L), Ok(O) states, if Low is set to 0.500kg and
High is set to 1.000kg, then 0.876 kg output is as follows.
S
T
,
G
O
,
+
0
.
8
7
6
k
g
<CR>
<LF>
HEAD1 , HEAD2 , DATA UNIT CR LF
1
.
0
0
0
<CR>
<LF>
F5
Function
Press key
Press key
Press key
twice after zeroing
r n p 0
RS232 command mode
Once received read weight command, transmit weight in
same format as r n p 1.
r n p 1
Stable transmission
After return to zero, transmit next stable weight.
r n p 2
Continuous transmission.
RS232 transmit continuously. Keypad has no effect.
r n p 3
Press key to transmit
totalized simple format
Transmit when
weight change
>±10d,
Transmit when
weight change
>±10d,
Print TOTAL and
clears totalized
values
r n p 4
Press key to transmit
totalized complete format.
Transmit when
weight change
>±10d,
Transmit when
weight change
>±10d,
Print TOTAL and
clears totalized
values
r n p 5
Stable transmission in totalizing
mode (After return to zero,
transmit next stable weight which
is > +10d)
No transmission
No transmission
Print TOTAL and
clears totalized
values
r n p 6
Press key to transmit
simple free format
Transmit when
weight change
>±10d,
Transmit when
weight change
>±10d,
Print TOTAL and
clears totalized
values
r n p 7
Press key to transmit
complete free format
Transmit when
weight change
>±10d,
Transmit when
weight change
>±10d,
Print TOTAL and
clears totalized
values
r n p 8
While use Hold, press key
to transmit same format as (r n P
1) and (r n P 2)
No transmission
Transmit as
stable weight
>±10d
No transmission,
totalized values not
cleared
r n p 9
Continuous Transmission (Brazil)
Continuous
transmission
Continuous
transmission
Continuous
transmission,
totalized values not
cleared
r n p 10
or key
Transmission (Brazil)
RS232 transmit
RS232 transmit
Print TOTAL and
clears totalized
values
r n p 11
Print after removing goods (5%
mode)
After placing item and become stable, beep twice. RS232
transmit item weight after item is removed.
DATA CR LF
