USE AND MAINTENANCE MANUALUSE AND MAINTENANCE MANUAL
Chain hoist from 198kg to 2500kg
■
■
■
■
■
■
■
■
■
■
■
■
■
compliance with LVD Low Voltage Directive;
compliance with EMC Electromagnetic Compatibility Directive;
compliance with EN 17206 standard;
compliance with EN 60204-1 standard;
compliance with EN 60204-32 standard;
be equipped with an emergency stop button compliant with EN ISO 13850;
be equipped with a control system designed to carry out single, not multiple lifting operations;
be able to start a lifting operation only by using a dead-man switch;
prevent automatic restart of the hoist after an emergency stop even if the dead-man switch is being
pressed;
prevent the automatic restart of the hoist after an emergency stop even if the "dead man" button is kept
pressed;
be able to remove current to the actuators and bring the machines to a Category 0 STOP if the
emergency stop is activated;
prevent the emergency stop function from being bypassed by other operating modes;
to be able to manage an automatic shutdown of the machines in use in case of overload in a multiple
lifting system.
CAUTIONCAUTION
Before connecting the control system, make sure that it is compatible with EXE RISE electric chain hoists.Before connecting the control system, make sure that it is compatible with EXE RISE electric chain hoists.
The power and control systems must also be chosen according to the maximum electrical absorption of each
individual EXE RISE electric chain hoist and the maximum number of hoists to be simultaneously moved to
perform a multiple lift.
EXE RISE electric chain hoists are standard wired for 400V-3ph-50Hz operations. For other voltages the motor
must be reconnected internally.
5.25.2 INSTALLATION AND USE OF THE CONTROL SYSTEMINSTALLATION AND USE OF THE CONTROL SYSTEM
CAUTIONCAUTION
The control system must be installed by competent personnel.The control system must be installed by competent personnel.
The control system must be located in an area that allows the operator an unimpeded view of all connected
machines. In this way the operator can have a full view and control of the lifting operation and ensure there are no
people in the area of exposure to danger from the handling of suspended loads.
The machine's control panel must be easily accessible by the operator.
In the case of use in low-light environments it is necessary to provide spot lighting near the control devices and in
the area where load handling operations take place.
The control system must be connected to the individual hoists so that the operator can easily recognize on the
control panel which hoist the individual control corresponds to.
WARNINGWARNING
Always check that the necessary safety conditions are met before carrying out the lifting operations.Always check that the necessary safety conditions are met before carrying out the lifting operations.
