USE AND MAINTENANCE MANUALUSE AND MAINTENANCE MANUAL
Chain hoist from 198kg to 2500kg
BODY FRAMEBODY FRAME RANGERANGE CAPACITYCAPACITY TYPETYPE REEVEREEVE CHAINCHAIN
D8+
198kg
SMALL FRAME 250kg DC / LVC 1 4x12mm
D8 198kg
D8+
198kg
MEDIUM FRAME COMPACT 250kg DC / LVC 1 5X15mm
D8 198kg
198kg
250kg DC / LVC
MEDIUM FRAME D8+ 500kg 1 6x18mm
250kg
SP
500kg
LARGE FRAME D8+
1000kg
DC / LVC
1
8x24mm
2000kg 2
EXTRA LARGE FRAME 1600kg
DC / LVC
1
10x28mm
COMPACT
D8+
3200kg 2
D8+
2000kg 1
EXTRA LARGE FRAME 4000kg DC / LVC 2 11.3x31mm
D8 2500kg 1
EXTRA EXTRA
D8+
2500kg
DC / LVC
1
13x36mm
LARGE FRAME 5000kg 2
The D8 and D8 + prefixes relate to the intended use of the machine as specified in paragraph 1.5.3 of this
operation and maintenance manual.
The DC and LVC suffixes indicate the type of electrical system on board the machine and are necessary to identify
the relevant control system to be integrated.
The SP suffix indicates that the machine model is powered by single-phase current. All other models are powered
by three-phase current.
Revisions to this operation and maintenance manual are listed in following table. The owner of the machine can
check the latest revision by contacting EXE TECHNOLOGY personnel.
Rev. No.Rev. No. Capitoli modificatiCapitoli modificati Amendments descriptionAmendments description Date of issueDate of issue
01 Entire manual First issue 25/11/2019
02 Entire manual Extra Large Frame integration 07/08/2020
03 Entire manual Content Update 14/12/2020
04 Entire manual Integrazione Medium Frame Compact 19/07/2022
