USE AND MAINTENANCE MANUALUSE AND MAINTENANCE MANUAL
Chain hoist from 198kg to 2500kg
N.N. Code LITECCode LITEC Product NameProduct Name NoteNote
01 999 Cover with handle Without screws
02 999 Screw UNI 5931 4 parts for Cover
02b 999 Screw UNI 5931 8x80mm 4 parts for Flange
03a 999 Brake unit size 12 (1st or 2nd) 103Vdc
Complete with fixing screws
for 1st and 2nd brake
03b LT XRS-0008 Rectifier and circuit breaker 230V AC / 105V DC Only for direct control
04 LT XRS-0161 Flange With 4 screws 02b
05a 999 Screw UNI 5931
05b 999 Screw UNI 5931
06 999 Brakes Housing Without screws
08 999 Extra Large Frame Gearbox KIT
With screws, bearings, pinion
and shaft
09a 999
Central Housing side Gearbox
09b 999 Central Housing side Stator
10 999 Swivel Body Hook KIT
11 999 Chain Bag Bracket KIT
12 999 Chain Bag Bracket KIT
15a 999 Internal chain guide plate
15b 999 External chain guide plate
16 LT XRC11M31-01M Chain Load
21 999 KIT Rotor+ Stator + Cluth 2ton
25 999 Chain block 11.3x31mm
26 999 KIT chain hook
27 999 Spirol Pin
28 LT AXCAVNE4G2.5 Power cable
PG16 hole plug (LT
AXCEM1052016N)
PG16 spiral cable gland (LT
XRS-0057)
38 999 Limit switch 2
39 999 Electronic board
Low Voltage Control OnlyLow Voltage Control Only
29 LT AXCAVNE4G2.5
Control cable CEE 16A 4h 24VAC – 3PH
+ G
30 999
Reversing Contactor 3P+T
200/250VAC 16A 9h 1P67
32 999
Screw Clamp Wieland WKM
4/15
33 999
Transformer T4 25VA
400/24VAC
34 999 Primary Fuse
35 999 Secondary Fuse
36 999 Rectifier 400-S
