Maintenance
46 EXFO EX1
Replacing the Battery
To replace the battery:
1. Turn off the EXFO EX1 device.
2. Unplug any power cable.
3. Using a screwdriver, remove the screw that is located on the back of
the EXFO EX1 device.
4. Remove the battery compartment door.
5. Remove the battery and disconnect the wires.
6. Replace the battery and reconnect the wires.
7. Close the battery compartment door.
8. Using a screwdriver, put the screw that was removed at step 3 back in
place.
CAUTION
Gently pull on the battery to avoid damaging the wires.
Screw
