Compact Modular Platform 111
6 Using the Optional Built-In
Power Meter and VFL
The FTB-200 v2 Compact Modular Platform can be equipped with an
optical power meter to measure absolute power (dBm or W) or insertion
loss (dB). The power meter can detect modulated signals (1 kHz, 2 kHz,
and 270 Hz).
The FTB-200 v2 can also include a visual fault locator (VFL) to inspect or
identify fibers.
For more information on how to use the power meter or the VFL, refer to
the power meter online help.
Note: The appearance of your application may vary depending on the options
that you have purchased and the module you are using. The illustrations
presented herafter show the application as it appears when the unit is
equipped with a built-in power meter and VFL.
