EXFO FTB-200 - A Technical Specifications

Compact Modular Platform 205
A Technical Specifications
IMPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS
a
Display Touchscreen, color, 640 x 480 TFT 163 mm (6.5 in)
Interfaces Two USB 2.0 ports
RJ-45 LAN 10/100/1000 Mbit/s
Fiber inspection probe connector port (video)
Built-in Bluetooth and Wi-Fi (hardware option)
Storage 8 GB internal memory (flash)
Battery
Rechargeable lithium-ion batteries
8 hours of operation as per Telcordia (Bellcore) GR-196
Power supply
AC/DC adapter, input 100-240 VAC, 50-60 Hz,
1.6 A max, output: 24 VDC, 90 W
Computer
Intel ATOM processor
Windows Embedded Standard
GENERAL SPECIFICATIONS
Temperature
Operating
Storage
b
0 °C to 50 °C (32 °F to 122 °F)
–40 °C to 60 °C (–40 °F to 140 °F)
Relative humidity 0 % to 95 % non-condensing
Size (H x W x D)
322 mm x 197 mm x 109 mm
(12
11
/ 16 in x 7 ¾ in x 4
5
/ 16 in)
Weight
b
2.1 kg (4.6 lb)
Vibration <1.5 g at 10 Hz to 500 Hz (on three main axes)
Mechanical shock <760 mm on six sides and eight main edges
(compliant to GR-196-CORE)
ACCESSORIES
FP4S 400x Fiber Inspection Probe GP-2028 Computer security cable kit
FP4D 200x/400x Fiber Inspection Probe GP-2112 3G Universal USB Dongle
GP-10-070 Rigid FTB-200 carrying case GP-2113 GPS USB Dongle
GP-10-072 Semi-rigid FTB-200 carrying case GP-2116 Single-slot storage module
GP-302 USB mouse GP-2137 USB-to-RS-232 converter
GP-1002 Headset GP-2138 DC car adapter/inverter
GP-1008 VFL adapter (2.5 mm to 1.25 mm) GP-2144 USB 16G micro-drive
GP-2001 USB keyboard GP-2155 Carry-on size backpack
c
GP-2016 10 feet RJ-45 LAN cable
