Test Setup - Test Configurator, Timer, and System
172 MAX-800 Series
Signal - Signal Configuration (DSn/PDH)
Loop-Up injects the selected loop up code. The loop code will be
generated continuously for a maximum of 10 seconds or until the
loopback is confirmed. After 10 seconds, if the loopback has failed,
a Loop-Down command is sent. A pop-up window appears
indicating the loop code injection progress and result. The text box
next to the Loop-Up button indicates the selected loop up code.
Loop-Down injects the selected loop down code. The loop code
will be generated continuously for a maximum of 10 seconds or
until the loopback is confirmed. After 10 seconds, if the loopback
has failed, a Loop-Down command is sent. A pop-up window
appears indicating the loop code injection progress and result. The
text box next to the Loop-Down button indicates the selected loop
down code.
Modify Loop Codes button
Allows the configuration of 10 DS1 loop code pairs. Configure each
loop code name, Loop-Up and Loop-Down values.
The name field allows up to 16 characters long. Loop-Up and
Loop-Down range is from 3 to 16 bits (000 to 1111111111111111).
The default DS1 loop codes correspond to the DS1 In-Band loop
codes (Loop-Up=10000, and Loop-Down=100).
NIU FAC2 (11000/11100) 11000 11100
NIU FAC3 (100000/100) 100000 100
Loopback Type
Command
Loop-Up Loop-Down
