Test Functions
320 MAX-800 Series
APS
Channel (Linear switching mode) or
Destination Node ID (Ring switching mode):
Bits 5 through 8 of the K1 byte.
 K2
Protected Channel (Linear switching mode) or
Source Node ID (Ring switching mode):
Bits 1 through 4 of the K2 byte.
Bits
5to8
Channel ID
(Linear mode)
Destination Node ID
(Ring mode)
Bits
5to8
Channel ID
(Linear mode)
Destination Node ID
(Ring mode)
0000 0 - Null
a
a. Default value.
0
a
1000 8 8
0001 1 1 1001 9 9
0010 2 2 1010 10 10
0011 3 3 1011 11 11
0100 4 4 1100 12 12
0101 5 5 1101 13 13
0110 6 6 1110 14 14
0111 7 7 1111 15 - Extra Traffic 15
Bits
1 to 4
Protected Channel
(Linear mode)
Source Node ID
(Ring mode)
Bits
1 to 4
Protected Channel
(Linear mode)
Source Node ID
(Ring mode)
0000 0 - Null
a
a. Default value.
0
a
1000 8 8
0001 1 1 1001 9 9
0010 2 2 1010 10 10
0011 3 3 1011 11 11
0100 4 4 1100 12 12
0101 5 5 1101 13 13
0110 6 6 1110 14 14
0111 7 7 1111 15 - Extra Traffic 15
