Test Control
MaxTester 383
Discover Remote Button
Remote Modules Discovery (3rd Party Loopback)
User Stream Destination from Test Application check box when
selected (default), it uses the stream destination configuration
parameters from the test application to communicate with the
third-party loopback unit. Only available with single-stream test
applications.
Loop Layer allows selecting the layer of loop messages: L2: Ethernet,
L3: IP, or L4: UDP/TCP.
Destination MAC Address
1
allows specifying the stream destination
MAC address.
Destination IP Address
1
(L3/4), allows specifying the stream
destination IP address.
Quick Ping tests if the destination IP address can be reached. A
message displays if the ping attempt is Successful or Failed.
Destination Port
1
(L4) allows selecting the stream destination UDP
port.
Remote Module ID indicates the unit ID of the remote unit.
Remote Status indicates the status of the remote unit.
1. Not configurable when the
User Stream Destination from Test Application
check box is selected.
