Exmark NAVIGATOR Parts Manual

JACKSHAFT GROUP
11
Item Part No. Description Qty.
1 1-303007 Washer ..................................................2
2 1-413088 Spacer ...................................................1
3 1-543017 Ball Joint (RH)........................................1
4 1-543610 Washer ..................................................1
5 1-603610 Washer, Spring Disk 7/16 ......................2
6 1-806003 Hairpin, Cotter........................................2
7 67-7490 Key, Machine 1/4 x 1/4 x 1 1/2...............1
8 92-9025 Spacer ...................................................2
9 103-6737 Belt, Matched Pair .................................1
10 103-0608 Ball Joint (RH)........................................1
11 103-1167 Ball Joint (LH) ........................................1
12 103-9486 Asm, PTO Handle W/Grip......................1
13 109-5491 Belt, Guide.............................................1
14 103-2535 Spacer, Guard Bottom ...........................1
15 103-2544 Asm, Jackshaft Housing W/Bearings.....1
16 103-2916 Guard, Top.............................................2
17 103-3504 Bearing, Spherical..................................2
18 103-3506 Seal, Single Lip......................................2
19 103-6732 Sheave ..................................................1
20 103-6735 Jackshaft ...............................................1
21 103-9439 Asm, Idler Sheave .................................1
22 103-8253 Asm, Idler Pivot......................................1
23 103-9295 Asm, Pivot W/Bushing ...........................1
24 103-9297 Asm, Arm W/Bushing ............................1
25 103-7350 Spacer, Idler ..........................................1
26 103-7382 Bushing..................................................1
27 103-9296 Asm, Arm W/Bushing ............................1
28 103-7392 Asm, Link Clutching...............................1
29 103-7393 Linkage, Rod..........................................1
30 103-7697 Band, Brake...........................................1
31 103-7994 Ball Joint (RH)........................................1
32 103-7996 Linkage, PTO Brake Rod .......................1
33 103-7997 Spring, Brake.........................................1
Item Part No. Description Qty.
34 103-9486 Asm, PTO Handle W/Grip ....................1
35 103-8254 Bushing, Spring ..................................... 2
36 103-8277 Link, Handle...........................................1
37 103-8716-03 Flag, Switch...........................................1
38 3256-24 Washer, 3/8 SAE................................... 2
39 103-9816 Spacer................................................... 1
40 106-7159 O-Ring [1.174 x .103]............................. 2
41 251-347 Bearing, Ball Deep Groove .................... 2
42 283-2 Pin, Clevis 3/8 x 1 1/6............................ 1
43 302-19 Zerk, 1/4-28 Str...................................... 1
44 322-3 Screw, HH 5/16-18 x 3/4........................ 2
45 322-6 Screw, HH 5/16-18 x 1 1/4.....................1
46 323-12 Screw, HH 3/8-16 x 2 1/2....................... 1
47 323-36 Screw, HH 3/8-16 x 7.............................1
48 323-6 Screw, HH 3/8-16 x 1............................. 4
49 323-9 Screw, HH 3/8-16 x 1 3/4....................... 2
50V 3212-6 Screw, HH 7/16-20 x 1 1/2..................... 1
51 3219-2 Nut, Hex 5/16-24.................................... 3
52 3219-20 Nut, Hex 3/8-24 LH................................ 1
53 3219-3 Nut, Hex 3/8-24...................................... 2
54 32151-13 Ring, Retaining...................................... 2
55 98-5975 Washer, Spring Disk 3/8........................ 5
56 3296-29 Nut, Nyloc 5/16-18................................. 1
57 3296-39 Nut, Nyloc 3/8-16...................................2
58 3296-6 Nut, Nyloc 3/8-24...................................1
59 32120-10 Ring, Retaining...................................... 2
60 103-8153 Grip, Control Lever ................................1
61 32128-20 Nut, Whizlock 5/16-18 ...........................2
62 32128-43 Nut, Whizlock 3/8-16 .............................2
63 32151-48 E-Ring ................................................... 2
64 108519 Bushing, Bronze .................................... 6
65 109-0148 Spring, Extension...................................1
66 5-0652 Spacer................................................... 1
Exmark black touch up spray paint - gloss black.
V Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on sheave bolt, item #50.

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
