Exmark NAVIGATOR Parts Manual

SPEED CONTROLS GROUP
7
Item Part No. Description Qty.
1 1-543017 Ball Joint, (RH).......................................3
2 1-633102 Bearing, Side Flange .............................2
3 1-633152 Ball Joint, (LH) .......................................3
4 1-804524 Nut, Hex 5/16-24 (LH)............................5
5 1-811010 Plug .......................................................4
6 103-3060 Knob, Tracking.......................................1
7 103-9468 Asm, Handle W/Grip..............................2
8 103-9730 Asm, Steering Lever W/Bearings (RH)...1
9 103-9731 Asm, Actuator W/Bearings (RH) ............1
10 103-9732 Asm, Actuator W/Bearings (LH).............1
11 103-4278 Shaft, Speed Control..............................1
12 103-4342-03 Wld, Hub Speed Control ........................2
13 103-4373 Spring, Extension...................................2
14 103-4377 Linkage, Rod Steering (LH)....................2
15 103-4397 Knob, Speed Control..............................1
16 103-4398 Bearing, Flange Iglide ............................8
17 103-9733 Asm, Steering Lever W/Bearings (LH) 1
18 103-5008 Wld, Control Arm ...................................1
19 103-5009 Disc, Friction..........................................2
20 103-5013 Wld, Speed Control Lever......................1
21 103-5016 Rod, Threaded Control Link ...................1
22 103-5017 Plate, Speed Control Friction .................1
23 103-5018 Washer, Spring Disk ..............................3
24 103-5064 Bearing, Plastic 1/2................................2
25 109-5927 Asm, Console W/Decals ........................1
26 103-5945 Spacer ...................................................1
27 103-5993-03 Guide, Plenum .......................................1
28 103-6078 Spring, Extension...................................1
29 103-6532 Spring, Extension...................................2
30 103-8494 Hook ......................................................1
Item Part No. Description Qty.
31 321-5 Screw, HH 1/4-20 x 7/8.......................... 4
32 321-8 Screw, HH 1/4-20 x 1 1/4....................... 1
33 322-3 Screw, HH 5/16-18 x 3/4........................ 6
34 322-6 Screw, HH 5/16-18 x 1 1/4.....................6
35 323-4 Screw, HH 3/8-16 x 3/4.......................... 4
36 323-8 Screw, HH 3/8-16 x 1 1/2....................... 2
37 322-5 Screw, HH 5/16-18 x 1...........................1
38 3217-6 Nut, Hex 5/16-18.................................... 2
39 3218-3 Nut, Jam 3/8-16.....................................1
40 3219-2 Nut, Hex 5/16-24.................................... 4
41 3245-1 Setscrew, 1/4-20 x 1/4........................... 6
42 3256-23 Washer, 5/16 SAE................................. 3
43 3256-24 Washer, 3/8 SAE................................... 2
44 3256-28 Washer, 3/4 SAE................................... 1
45 3256-3 Washer, 5/16 Std................................... 9
46 3257-5 Key, Woodruff #9 3/4 x 3/16 ..................3
47 3290-357 Nut, Whizlock 3/8-16 .............................8
48 3296-19 Nut, Nyloc 1/2-20...................................1
49 3296-29 Nut, Nyloc 5/16-18................................. 7
50 32128-20 Nut, Whizlock 5/16-18 ...........................1
51 32128-33 Nut, Whizlock 1/4-20 .............................6
52 32151-48 E-Ring ................................................... 1
53 1-323245 Spring, Compression ............................. 4
54 103-5994 Grip, Steering Handle ............................2
55 103-9468 Asm, Handle W/Grip..............................2
56 103-8425 Decal, Driveline .....................................1
57 103-9493 Asm, Pump Linkage (RH)...................... 1
58 103-9492 Asm, Pump Linkage (LH).......................1
59 109-4273 Decal, Wheel Motor Release .................1
Exmark black touch up spray paint – Gloss black.

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
